Case
Material: Grade 5 titanium/steel or green ceramic-coated grade 5 titanium/steel
Dimensions: 43mm width, 51mm length, 15.8mm height
Crystal: Sapphire crystal
Water resistance: Pressure tested to 30m / 3ATM
Finishing: Satin finish; bead-blasted
Movement
Caliber UR-EMC2 caliber conceived, developed and manufactured by URWERK
Escapement Swiss lever escapement
Balance wheel In ARCAP P40, linear balance coupled to the optical sensor
Frequency 4 Hz /28,800 vph
Balance spring Flat
Energy source Vertically mounted double mainspring barrels connected in series
Power reserve 80 hours
Winding Manual winding
Finishing: Côtes de Genève, snailing, micro-bead blasting, polished bevels on screw
heads
EMC
Generator Maxon® generator with manual winding charging super capacitor
EMC system Optical sensor controlled by an integrated circuit board ;
16,000,000 Hz reference oscillator
Indications Hours, minutes, seconds; precision delta, amplitude, power reserve.
Timing adjustment screw
